Features:
• Max. speed 4000rpm.
• Rotor speed can be set in RPM/RCF, with 3 programs storage capacity for routine applications.
• Max. capacity 50ml×4, Adapt to difffferent sizes of blood collection tubes and centrifuge tubes suitable for swing out rotor and angle rotor.
• Automatic internal diagnosis and self-detection.
• Maintenance-free brushless DC motor.
Specifications | 01-860X | 01-870X | |
Speed range | 500-4000rpm increment: 100rpm | 300-4000rpm increment: 100rpm | |
Max. RCF | 2500×g | 1900×g | |
Speed accuracy | ±100rpm | ±100rpm | |
| Rotor | Swing6×15ml Swing4×50ml Angle 24×15 ml, Angle 12×10ml/8×15ml | Angel 8×15ml (Default), Angel 10ml×12 | |
| Run time | 1-99min, HOLD | 1-99min, HOLD | |
Motor | Brushless DC motor | Brushless DC motor | |
Display | LCD | LED | |
Program | Blood: 3200rpm10min. Urine: 1800rpm5min. Faecal: 1300rpm10min. | Blood: 3200rpm, 10min Urine: 1800rpm,5min Faecal: 1300rpm, 10min | |
Safety Device | Automatic internal diagnosis | Automatic internal diagnosis | |
Acceleration/deceleration | 3↑4↓steps | 25s↑35s↓ | |
Power | Single phase, 100V-240V, 50Hz/60Hz | Single phase, 100V-240V, 50Hz/60Hz | |
Dimension(W×D×H) | 364×440×268mm | 286×367× 227mm | |
Weight | 14.5kg | 9.2kg | |
Noise | ≤62dB(A) | ≤60dB(A) |
X: 1-US plug 4-Eur plug 5-UK plug
